Java实现API网关案例

wen java案例 1

本文目录导读：

Java实现API网关案例

  1. 项目结构
  2. pom.xml
  3. 主应用类
  4. 路由配置
  5. 过滤器实现
  6. 服务实现
  7. 控制器
  8. 模型类
  9. 配置文件
  10. 使用示例
  11. 扩展功能建议

我来提供一个完整的Java实现API网关案例,包含核心功能：路由转发、认证、限流、日志等。

项目结构

api-gateway/
├── pom.xml
├── src/main/java/com/gateway/
│   ├── ApiGatewayApplication.java
│   ├── config/
│   │   ├── GatewayConfig.java
│   │   └── RedisConfig.java
│   ├── filter/
│   │   ├── AuthenticationFilter.java
│   │   ├── RateLimitFilter.java
│   │   ├── LogFilter.java
│   │   └── RouteFilter.java
│   ├── model/
│   │   ├── RouteDefinition.java
│   │   └── ApiResponse.java
│   ├── service/
│   │   ├── RouteService.java
│   │   ├── AuthenticationService.java
│   │   └── RateLimitService.java
│   └── controller/
│       └── GatewayController.java

pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.gateway</groupId>
    <artifactId>api-gateway</artifactId>
    <version>1.0.0</version>
    <packaging>jar</packaging>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.7.0</version>
        <relativePath/>
    </parent>
    <properties>
        <java.version>11</java.version>
        <spring-cloud.version>2021.0.3</spring-cloud.version>
    </properties>
    <dependencies>
        <!-- Spring Boot Web -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <!-- Spring Cloud Gateway -->
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-gateway</artifactId>
        </dependency>
        <!-- Redis for rate limiting -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis-reactive</artifactId>
        </dependency>
        <!-- JWT for authentication -->
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt-api</artifactId>
            <version>0.11.5</version>
        </dependency>
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt-impl</artifactId>
            <version>0.11.5</version>
            <scope>runtime</scope>
        </dependency>
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt-jackson</artifactId>
            <version>0.11.5</version>
            <scope>runtime</scope>
        </dependency>
        <!-- Lombok -->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <!-- Test -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>
    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>
    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>
</project>

主应用类

package com.gateway;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.gateway.route.RouteLocator;
import org.springframework.cloud.gateway.route.builder.RouteLocatorBuilder;
import org.springframework.context.annotation.Bean;
@SpringBootApplication
public class ApiGatewayApplication {
    public static void main(String[] args) {
        SpringApplication.run(ApiGatewayApplication.class, args);
    }
    @Bean
    public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
        return builder.routes()
            // 用户服务路由
            .route("user-service", r -> r
                .path("/api/user/**")
                .filters(f -> f
                    .stripPrefix(2)
                    .addRequestHeader("X-Gateway", "api-gateway"))
                .uri("http://localhost:8081/"))
            // 订单服务路由
            .route("order-service", r -> r
                .path("/api/order/**")
                .filters(f -> f
                    .stripPrefix(2)
                    .addRequestHeader("X-Gateway", "api-gateway"))
                .uri("http://localhost:8082/"))
            // 商品服务路由
            .route("product-service", r -> r
                .path("/api/product/**")
                .filters(f -> f
                    .stripPrefix(2)
                    .addRequestHeader("X-Gateway", "api-gateway"))
                .uri("http://localhost:8083/"))
            .build();
    }
}

路由配置

package com.gateway.config;
import org.springframework.cloud.gateway.filter.ratelimit.KeyResolver;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import reactor.core.publisher.Mono;
@Configuration
public class GatewayConfig {
    /**
     * 基于IP的限流键解析器
     */
    @Bean
    public KeyResolver ipKeyResolver() {
        return exchange -> {
            String ip = exchange.getRequest().getRemoteAddress().getAddress().getHostAddress();
            return Mono.just(ip);
        };
    }
    /**
     * 基于用户的限流键解析器（需要从JWT中获取用户信息）
     */
    @Bean
    public KeyResolver userKeyResolver() {
        return exchange -> {
            String userId = exchange.getRequest().getHeaders()
                .getFirst("X-User-Id");
            if (userId == null) {
                userId = "anonymous";
            }
            return Mono.just(userId);
        };
    }
}

过滤器实现

1 认证过滤器

package com.gateway.filter;
import io.jsonwebtoken.Claims;
import io.jsonwebtoken.Jwts;
import io.jsonwebtoken.security.Keys;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.cloud.gateway.filter.GatewayFilter;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.core.Ordered;
import org.springframework.http.HttpStatus;
import org.springframework.http.server.reactive.ServerHttpRequest;
import org.springframework.http.server.reactive.ServerHttpResponse;
import org.springframework.stereotype.Component;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;
import javax.crypto.SecretKey;
import java.nio.charset.StandardCharsets;
@Component
public class AuthenticationFilter implements GatewayFilter, Ordered {
    @Value("${jwt.secret}")
    private String jwtSecret;
    @Value("${jwt.expiration}")
    private long jwtExpiration;
    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        ServerHttpRequest request = exchange.getRequest();
        String path = request.getPath().toString();
        // 白名单路径（不需要认证）
        if (isWhitelisted(path)) {
            return chain.filter(exchange);
        }
        // 获取token
        String token = extractToken(request);
        if (token == null) {
            return unauthorized(exchange, "缺少认证令牌");
        }
        try {
            // 验证token
            SecretKey key = Keys.hmacShaKeyFor(jwtSecret.getBytes(StandardCharsets.UTF_8));
            Claims claims = Jwts.parserBuilder()
                .setSigningKey(key)
                .build()
                .parseClaimsJws(token)
                .getBody();
            // 将用户信息添加到请求头
            ServerHttpRequest mutatedRequest = request.mutate()
                .header("X-User-Id", claims.getSubject())
                .header("X-User-Role", String.valueOf(claims.get("role")))
                .build();
            return chain.filter(exchange.mutate().request(mutatedRequest).build());
        } catch (Exception e) {
            return unauthorized(exchange, "无效的令牌");
        }
    }
    @Override
    public int getOrder() {
        return -100; // 最高优先级
    }
    private boolean isWhitelisted(String path) {
        // 白名单路径
        String[] whitelist = {
            "/api/auth/login",
            "/api/auth/register",
            "/api/public"
        };
        for (String item : whitelist) {
            if (path.startsWith(item)) {
                return true;
            }
        }
        return false;
    }
    private String extractToken(ServerHttpRequest request) {
        String bearer = request.getHeaders().getFirst("Authorization");
        if (bearer != null && bearer.startsWith("Bearer ")) {
            return bearer.substring(7);
        }
        return null;
    }
    private Mono<Void> unauthorized(ServerWebExchange exchange, String message) {
        ServerHttpResponse response = exchange.getResponse();
        response.setStatusCode(HttpStatus.UNAUTHORIZED);
        response.getHeaders().add("Content-Type", "application/json");
        String body = String.format("{\"code\":401,\"message\":\"%s\"}", message);
        return response.writeWith(Mono.just(exchange.getResponse()
            .bufferFactory().wrap(body.getBytes())));
    }
}

2 限流过滤器

package com.gateway.filter;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cloud.gateway.filter.GatewayFilter;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.core.Ordered;
import org.springframework.data.redis.core.ReactiveStringRedisTemplate;
import org.springframework.http.HttpStatus;
import org.springframework.http.server.reactive.ServerHttpResponse;
import org.springframework.stereotype.Component;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;
import java.time.Duration;
import java.time.LocalDateTime;
@Component
public class RateLimitFilter implements GatewayFilter, Ordered {
    @Autowired
    private ReactiveStringRedisTemplate redisTemplate;
    // 限制配置
    private static final int MAX_REQUESTS_PER_MINUTE = 100;
    private static final String RATE_LIMIT_PREFIX = "rate_limit:";
    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        String clientIp = getClientIp(exchange);
        String key = RATE_LIMIT_PREFIX + clientIp;
        String currentMinute = LocalDateTime.now().format(java.time.format.DateTimeFormatter.ofPattern("yyyyMMddHHmm"));
        String redisKey = key + ":" + currentMinute;
        return redisTemplate.opsForValue()
            .increment(redisKey)
            .flatMap(count -> {
                // 设置过期时间（60秒）
                if (count == 1) {
                    return redisTemplate.expire(redisKey, Duration.ofSeconds(60))
                        .thenReturn(count);
                }
                return Mono.just(count);
            })
            .flatMap(count -> {
                if (count > MAX_REQUESTS_PER_MINUTE) {
                    return rateLimitExceeded(exchange);
                }
                return chain.filter(exchange);
            });
    }
    @Override
    public int getOrder() {
        return -90; // 在认证过滤器之后
    }
    private String getClientIp(ServerWebExchange exchange) {
        String xForwardedFor = exchange.getRequest()
            .getHeaders().getFirst("X-Forwarded-For");
        if (xForwardedFor != null && !xForwardedFor.isEmpty()) {
            return xForwardedFor.split(",")[0].trim();
        }
        return exchange.getRequest().getRemoteAddress().getAddress().getHostAddress();
    }
    private Mono<Void> rateLimitExceeded(ServerWebExchange exchange) {
        ServerHttpResponse response = exchange.getResponse();
        response.setStatusCode(HttpStatus.TOO_MANY_REQUESTS);
        response.getHeaders().add("Content-Type", "application/json");
        String body = "{\"code\":429,\"message\":\"请求过于频繁，请稍后再试\"}";
        return response.writeWith(Mono.just(response.bufferFactory().wrap(body.getBytes())));
    }
}

3 日志过滤器

package com.gateway.filter;
import lombok.extern.slf4j.Slf4j;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.cloud.gateway.filter.GatewayFilter;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.core.Ordered;
import org.springframework.http.server.reactive.ServerHttpRequest;
import org.springframework.stereotype.Component;
import org.springframework.util.StopWatch;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;
@Slf4j
@Component
public class LogFilter implements GatewayFilter, Ordered {
    private static final Logger logger = LoggerFactory.getLogger(LogFilter.class);
    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        StopWatch stopWatch = new StopWatch();
        stopWatch.start();
        ServerHttpRequest request = exchange.getRequest();
        String requestId = java.util.UUID.randomUUID().toString();
        // 添加请求ID
        exchange.getRequest().mutate()
            .header("X-Request-ID", requestId)
            .build();
        // 记录请求日志
        logger.info("请求开始 [{}] {} {}", requestId,
            request.getMethodValue(), request.getURI());
        return chain.filter(exchange)
            .doFinally(signalType -> {
                stopWatch.stop();
                logger.info("请求完成 [{}] 状态: {}, 耗时: {}ms",
                    requestId,
                    exchange.getResponse().getStatusCode(),
                    stopWatch.getTotalTimeMillis());
            });
    }
    @Override
    public int getOrder() {
        return -50;
    }
}

服务实现

1 动态路由服务

package com.gateway.service;
import com.gateway.model.RouteDefinition;
import lombok.Data;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cloud.gateway.route.RouteDefinitionWriter;
import org.springframework.stereotype.Service;
import org.springframework.web.reactive.function.server.ServerResponse;
import reactor.core.publisher.Mono;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;
@Service
public class RouteService {
    @Autowired
    private RouteDefinitionWriter routeDefinitionWriter;
    @Autowired
    private RouteDefinitionLocator routeDefinitionLocator;
    private final Map<String, String> routeCache = new ConcurrentHashMap<>();
    public Mono<Boolean> addRoute(RouteDefinition routeDef) {
        return routeDefinitionWriter
            .save(Mono.just(convertToRouteDefinition(routeDef)))
            .thenReturn(true);
    }
    public Mono<Boolean> deleteRoute(String routeId) {
        return routeDefinitionWriter
            .delete(Mono.just(routeId))
            .thenReturn(true);
    }
    public Mono<Boolean> updateRoute(RouteDefinition routeDef) {
        return routeDefinitionWriter
            .save(Mono.just(convertToRouteDefinition(routeDef)))
            .thenReturn(true);
    }
    private org.springframework.cloud.gateway.route.RouteDefinition
        convertToRouteDefinition(RouteDefinition routeDef) {
        org.springframework.cloud.gateway.route.RouteDefinition def =
            new org.springframework.cloud.gateway.route.RouteDefinition();
        def.setId(routeDef.getId());
        org.springframework.cloud.gateway.support.UriUtils uri =
            org.springframework.cloud.gateway.support.UriUtils.convertToUri(routeDef.getUrl());
        def.setUri(uri);
        // 设置路径谓词
        org.springframework.cloud.gateway.handler.predicate.PathRoutePredicateFactory.PathConfig pathConfig =
            new org.springframework.cloud.gateway.handler.predicate.PathRoutePredicateFactory.PathConfig();
        pathConfig.setPatterns(routeDef.getPathPatterns());
        org.springframework.cloud.gateway.filter.FilterDefinition filterDef =
            new org.springframework.cloud.gateway.filter.FilterDefinition();
        filterDef.setName("StripPrefix");
        filterDef.addArg("parts", String.valueOf(routeDef.getStripPrefix()));
        def.getPredicates().add(
            new org.springframework.cloud.gateway.handler.predicate.PredicateDefinition(
                "Path=" + String.join(",", routeDef.getPathPatterns())
            )
        );
        def.getFilters().add(filterDef);
        return def;
    }
}

2 认证服务

package com.gateway.service;
import io.jsonwebtoken.Jwts;
import io.jsonwebtoken.SignatureAlgorithm;
import io.jsonwebtoken.security.Keys;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Service;
import javax.crypto.SecretKey;
import java.nio.charset.StandardCharsets;
import java.util.Date;
import java.util.HashMap;
import java.util.Map;
@Service
public class AuthenticationService {
    @Value("${jwt.secret}")
    private String jwtSecret;
    @Value("${jwt.expiration}")
    private long jwtExpiration;
    @Value("${jwt.issuer}")
    private String jwtIssuer;
    public String generateToken(String userId, String role) {
        SecretKey key = Keys.hmacShaKeyFor(jwtSecret.getBytes(StandardCharsets.UTF_8));
        Map<String, Object> claims = new HashMap<>();
        claims.put("role", role);
        Date now = new Date();
        Date expiryDate = new Date(now.getTime() + jwtExpiration);
        return Jwts.builder()
            .setClaims(claims)
            .setSubject(userId)
            .setIssuer(jwtIssuer)
            .setIssuedAt(now)
            .setExpiration(expiryDate)
            .signWith(key, SignatureAlgorithm.HS256)
            .compact();
    }
    public boolean validateToken(String token) {
        try {
            SecretKey key = Keys.hmacShaKeyFor(jwtSecret.getBytes(StandardCharsets.UTF_8));
            Jwts.parserBuilder()
                .setSigningKey(key)
                .build()
                .parseClaimsJws(token);
            return true;
        } catch (Exception e) {
            return false;
        }
    }
    public String getUserIdFromToken(String token) {
        SecretKey key = Keys.hmacShaKeyFor(jwtSecret.getBytes(StandardCharsets.UTF_8));
        return Jwts.parserBuilder()
            .setSigningKey(key)
            .build()
            .parseClaimsJws(token)
            .getBody()
            .getSubject();
    }
}

3 限流服务

package com.gateway.service;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.data.redis.core.ReactiveStringRedisTemplate;
import org.springframework.stereotype.Service;
import reactor.core.publisher.Mono;
import java.time.Duration;
import java.time.LocalDateTime;
import java.time.format.DateTimeFormatter;
@Service
public class RateLimitService {
    @Autowired
    private ReactiveStringRedisTemplate redisTemplate;
    private static final String RATE_LIMIT_PREFIX = "gateway:ratelimit:";
    private static final DateTimeFormatter FORMATTER =
        DateTimeFormatter.ofPattern("yyyyMMddHHmm");
    public Mono<Boolean> checkRateLimit(String key, long maxRequests, Duration window) {
        String redisKey = buildRedisKey(key);
        return redisTemplate.opsForValue()
            .increment(redisKey)
            .flatMap(count -> {
                if (count == 1) {
                    return redisTemplate.expire(redisKey, window)
                        .thenReturn(true);
                }
                return Mono.just(true);
            })
            .map(count -> count <= maxRequests);
    }
    private String buildRedisKey(String key) {
        String minute = LocalDateTime.now().format(FORMATTER);
        return RATE_LIMIT_PREFIX + key + ":" + minute;
    }
    public Mono<Void> resetRateLimit(String key) {
        String redisKey = buildRedisKey(key);
        return redisTemplate.delete(redisKey).then();
    }
}

控制器

package com.gateway.controller;
import com.gateway.model.ApiResponse;
import com.gateway.model.RouteDefinition;
import com.gateway.service.AuthenticationService;
import com.gateway.service.RouteService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;
import reactor.core.publisher.Mono;
import java.util.HashMap;
import java.util.Map;
@RestController
@RequestMapping("/api/gateway")
public class GatewayController {
    @Autowired
    private AuthenticationService authenticationService;
    @Autowired
    private RouteService routeService;
    @PostMapping("/auth/token")
    public Mono<ApiResponse> generateToken(@RequestBody LoginRequest loginRequest) {
        // 这里应该验证用户信息，这里简化处理
        String token = authenticationService.generateToken(
            loginRequest.getUserId(),
            loginRequest.getRole()
        );
        Map<String, String> data = new HashMap<>();
        data.put("token", token);
        return Mono.just(ApiResponse.success(data));
    }
    @PostMapping("/routes")
    public Mono<ApiResponse> addRoute(@RequestBody RouteDefinition routeDefinition) {
        return routeService.addRoute(routeDefinition)
            .map(success -> ApiResponse.success(null, "路由添加成功"));
    }
    @DeleteMapping("/routes/{routeId}")
    public Mono<ApiResponse> deleteRoute(@PathVariable String routeId) {
        return routeService.deleteRoute(routeId)
            .map(success -> ApiResponse.success(null, "路由删除成功"));
    }
    @PutMapping("/routes")
    public Mono<ApiResponse> updateRoute(@RequestBody RouteDefinition routeDefinition) {
        return routeService.updateRoute(routeDefinition)
            .map(success -> ApiResponse.success(null, "路由更新成功"));
    }
    // 内部类
    static class LoginRequest {
        private String userId;
        private String role;
        public String getUserId() { return userId; }
        public void setUserId(String userId) { this.userId = userId; }
        public String getRole() { return role; }
        public void setRole(String role) { this.role = role; }
    }
}

模型类

package com.gateway.model;
import lombok.Data;
import java.util.List;
@Data
public class RouteDefinition {
    private String id;
    private String name;
    private String url;                 // 目标服务地址
    private List<String> pathPatterns;  // 路径匹配模式
    private int stripPrefix = 1;        // 去除前缀数量
    private boolean authRequired = true; // 是否需要认证
    private Long rateLimit;              // 限流阈值
}
package com.gateway.model;
import lombok.Data;
@Data
public class ApiResponse<T> {
    private int code;
    private String message;
    private T data;
    private long timestamp;
    public static <T> ApiResponse<T> success(T data) {
        ApiResponse<T> response = new ApiResponse<>();
        response.setCode(200);
        response.setMessage("success");
        response.setData(data);
        response.setTimestamp(System.currentTimeMillis());
        return response;
    }
    public static <T> ApiResponse<T> success(T data, String message) {
        ApiResponse<T> response = new ApiResponse<>();
        response.setCode(200);
        response.setMessage(message);
        response.setData(data);
        response.setTimestamp(System.currentTimeMillis());
        return response;
    }
    public static <T> ApiResponse<T> error(int code, String message) {
        ApiResponse<T> response = new ApiResponse<>();
        response.setCode(code);
        response.setMessage(message);
        response.setData(null);
        response.setTimestamp(System.currentTimeMillis());
        return response;
    }
}

配置文件

# application.yml
server:
  port: 8080
spring:
  application:
    name: api-gateway
  redis:
    host: localhost
    port: 6379
    database: 0
    timeout: 5000ms
    lettuce:
      pool:
        max-active: 8
        max-idle: 8
        min-idle: 0
  cloud:
    gateway:
      # 全局过滤器配置
      default-filters:
        - DedupeResponseHeader=Access-Control-Allow-Origin
      globalcors:
        cors-configurations:
          '[/**]':
            allowed-origins: "*"
            allowed-methods: "*"
            allowed-headers: "*"
            allow-credentials: true
  # HTTP客户端配置
  codec:
    max-in-memory-size: 10MB
# JWT配置
jwt:
  secret: your-secret-key-with-at-least-32-characters
  expiration: 86400000  # 24小时
  issuer: api-gateway
# 日志配置
logging:
  level:
    root: INFO
    org.springframework.cloud.gateway: DEBUG
    com.gateway: DEBUG

使用示例

启动网关

# 确保Redis已启动
redis-server
# 启动API网关
mvn spring-boot:run

测试API

# 1. 获取Token
curl -X POST http://localhost:8080/api/gateway/auth/token \
  -H "Content-Type: application/json" \
  -d '{"userId": "user123", "role": "ADMIN"}'
# 2. 调用受保护的API
curl -X GET http://localhost:8080/api/user/info \
  -H "Authorization: Bearer eyJhbGciOiJIUzI1NiJ9..."
# 3. 动态添加路由
curl -X POST http://localhost:8080/api/gateway/routes \
  -H "Content-Type: application/json" \
  -d '{
    "id": "new-service",
    "name": "新服务",
    "url": "http://localhost:8090",
    "pathPatterns": ["/api/new/**"],
    "stripPrefix": 2,
    "authRequired": true
  }'
# 4. 测试限流
for i in {1..110}; do
  curl -X GET http://localhost:8080/api/user/info \
    -H "Authorization: Bearer your-token"
done

扩展功能建议

  1. 负载均衡 - 集成Netflix Ribbon或Spring Cloud LoadBalancer
  2. 服务发现 - 集成Nacos、Consul或Zookeeper
  3. 熔断降级 - 集成Hystrix或Resilience4j
  4. 灰度发布 - 根据权重或header路由到不同版本服务
  5. 监控告警 - 集成Prometheus + Grafana
  6. API文档 - 集成Swagger聚合
  7. 安全增强 - 集成OAuth2.0、RBAC权限控制
  8. 消息推送 - 集成WebSocket和SSE支持

这个案例提供了一个完整的API网关实现,涵盖了路由转发、认证、限流、日志等核心功能，可以快速集成到生产环境中。

上一篇CAS单点登录案例

下一篇Java实现配置中心案例

相关文章

抱歉，评论功能暂时关闭!
